原料比对
产品信息
品名
品牌名
典型应用
特性
认证
ABS 3001G 日本UMG
UMG ABS®
--
--
UL
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
物性数据
| 热性能 | 测试条件 | 测试方法 | 日本UMG/3001G |
|---|---|---|---|
| UL阻燃等级 | UL 94 | HB | |
| 燃烧性（率） | UL 94 | HB | |
| 热变形温度 | 1.8MPa,未退火 | ISO 75-2/Af | 83.0 °C |
| HDT | 83 °C | ||
| HDT | ASTM D648/ISO 75 | 83 ℃（℉） | |
| 线性热膨胀系数 | MD | ISO 11359-2 | 8.5E-05 cm/cm/°C |
| 其他 | 测试条件 | 测试方法 | 日本UMG/3001G |
|---|---|---|---|
| 特性 | 抗疲劳 |
| 物性性能 | 测试条件 | 测试方法 | 日本UMG/3001G |
|---|---|---|---|
| 熔体质量流动速率 | ASTM D1238/ISO 1133 | 5 g/10min |
| 机械性能 | 测试条件 | 测试方法 | 日本UMG/3001G |
|---|---|---|---|
| 简支梁缺口冲击强度 | ASTM D256/ISO 179 | 28 kg·cm/cm(J/M)ft·lb/in | |
| 28 kJ/m² | |||
| 拉伸模量 | 23°C | ISO 527-2 | 2350 Mpa |
| 拉伸强度 | 23°C | ISO 527-2 | 45.0 Mpa |
| 弯曲模量 | 23°C | ISO 178 | 2600 Mpa |
| 2600 Mpa | |||
| ASTM D790/ISO 178 | 2.600 kg/cm²(MPa)[Lb/in²] | ||
| 弯曲强度 | 23°C | ISO 178 | 72.0 Mpa |
| 基本性能 | 测试条件 | 测试方法 | 日本UMG/3001G |
|---|---|---|---|
| 熔体质量流动速率 | 5 g/10min |
| 硬度 | 测试条件 | 测试方法 | 日本UMG/3001G |
|---|---|---|---|
| 洛氏硬度 | R计秤,23°C | ISO 2039-2 | 109 |
| 可燃性 | 测试条件 | 测试方法 | 日本UMG/3001G |
|---|---|---|---|
| UL阻燃等级 | 1.5mm | UL 94 | HB |
| 物理性能 | 测试条件 | 测试方法 | 日本UMG/3001G |
|---|---|---|---|
| 熔体体积流动速率 | 220°C/10.0kg | ISO 1133 | 5.00 cm3/10min |
| 收缩率 | MD：23°C | ISO 294-4 | 0.40-0.60 % |
