ABS 420 TECHNO JAPAN
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
Plastic Datasheets
| hardness | Test Condition | Test Method | TECHNO JAPAN/420 |
|---|---|---|---|
| Rockwell hardness | R计秤 | ISO2039-2 | 118 |
| Mechanical properties | Test Condition | Test Method | TECHNO JAPAN/420 |
|---|---|---|---|
| Tensile stress | 屈服 | ISO527-2 | 63.0 Mpa |
| Bending stress | ISO178 | 95.0 Mpa | |
| Flexural modulus | ISO178 | 2840 Mpa |
| flammability | Test Condition | Test Method | TECHNO JAPAN/420 |
|---|---|---|---|
| UL flame retardant rating | ALL | UL94 | HB |
| physical property | Test Condition | Test Method | TECHNO JAPAN/420 |
|---|---|---|---|
| melt mass-flow rate | 220°C/10.0kg | ISO1133 | 20 g/10min |
| Shrinkage rate | ISO294-4 | 0.50到0.80 % |
| Thermal performance | Test Condition | Test Method | TECHNO JAPAN/420 |
|---|---|---|---|
| Heat Deflection Temperature | 0.45MPa,未退火 | ISO75-2/B | 106 °C |
| 1.8MPa,未退火 | ISO75-2/A | 78.0 °C |
