ABS VN30 BK ASAHI JAPAN
XYRON™
--
--
UL
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
Plastic Datasheets
| Impact resistance | Test Condition | Test Method | ASAHI JAPAN/VN30 BK |
|---|---|---|---|
| Charpy Notched Impact Strength | 23°C | ISO 179 | 6.0 kJ/m² |
| Electrical performance | Test Condition | Test Method | ASAHI JAPAN/VN30 BK |
|---|---|---|---|
| Volume resistivity | 23°C | IEC 60093 | 1E+16 ohms·cm |
| Surface Resistivity | IEC 60093 | 1E+16 ohms |
| Mechanical properties | Test Condition | Test Method | ASAHI JAPAN/VN30 BK |
|---|---|---|---|
| bending strength | 23°C | ISO 178 | 78.0 Mpa |
| tensile strength | 屈服,23°C | ISO 527-2 | 46.0 Mpa |
| Flexural modulus | 23°C | ISO 178 | 2000 Mpa |
| Nominal tensile fracture strain | 23°C | ISO 527-2 | 30 % |
| flammability | Test Condition | Test Method | ASAHI JAPAN/VN30 BK |
|---|---|---|---|
| UL flame retardant rating | 1.50mm | UL 94 | V-1 |
| physical property | Test Condition | Test Method | ASAHI JAPAN/VN30 BK |
|---|---|---|---|
| Shrinkage rate | 2.00mm | 内部方法 | 0.50-0.70 % |
| Water absorption rate | 23°C,24hr | ISO 62 | 0.060 % |
| Thermal performance | Test Condition | Test Method | ASAHI JAPAN/VN30 BK |
|---|---|---|---|
| 1.8MPa, Not annealed | ASTM D648 | 100 °C | |
| Linear coefficient of thermal expansion | MD：-30到65°C | ISO 11359-2 | 7.5E-05 cm/cm/°C |
| 1.8MPa, Not annealed | ISO 75-2/A | 96.0 °C |
