ABS MG47 TIANJIN DAGU
红三晶
small home appliances
High gloss、High impact resistance、Low temperature resistanc、High toughness、Medium resistance
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
Plastic Datasheets
| Mechanical properties | Test Condition | Test Method | TIANJIN DAGU/MG47 |
|---|---|---|---|
| bending strength | 1/8",1.3mm/min | ASTM D-790 | 770 kg/cm2 |
| Rockwell hardness | ASTM D-785 | 112 R scale | |
| IZOD impact strength | 1/8",23℃ | ASTM D-256 | 25 kg.cm/cm |
| Stretching rate | 1/8",50mm/min | ASTM D-638 | 40 % |
| Flexural modulus | 1/8",1.3mm/min | ASTM D-790 | 25180 kg/cm2 |
| tensile strength | 1/8",50mm/min | ASTM D-638 | 510 kg/cm2 |
| physical property | Test Condition | Test Method | TIANJIN DAGU/MG47 |
|---|---|---|---|
| melt mass-flow rate | 220℃/10kg | ASTM D-1238 | 15.5 g/10min |
| Shrinkage rate | ASTM D-955 | 0.5-0.8 % | |
| density | 23℃ | ASTM D-792 | 1.045 |
| Thermal performance | Test Condition | Test Method | TIANJIN DAGU/MG47 |
|---|---|---|---|
| vicat | 1kg | ASTM D-1525 | 99 °C |
| 1/8",1.8MPa | ASTM D-648 | 80 °C | |
| Combustion heat | 1/8" | UL 94 | HB |
